10TDN1000-1X/PWR20A00-P2,2-V-S10 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TDN1000-1X/PWR20A00-P2,2-V-S10 (1015955B) is a sophisticated hydraulic tank-mounted return line filter designed for efficient solid filtration from liquids in hydraulic or lubrication systems. This duplex filter features a multilayer glass fiber material designated as PWR20, which ensures high filtration efficiency and durability. It is equipped with an optical indicator for easy monitoring and features a segment change-over valve for seamless operation. The filter is built to withstand a maximum working pressure of 10 bar and has a nominal pressure rating of 10 bar, making it suitable for demanding applications. Its housing is made from aluminum, providing both strength and lightweight characteristics. The filter's design includes an FKM seal code, ensuring compatibility with various fluids and offering reliable sealing performance. The port designation of 3'' - 3000psi in horizontal position adheres to the SAE standard, facilitating easy integration into existing systems. With a bypass cracking pressure set at 3.5 bar, it helps maintain system integrity by allowing fluid flow even if the filter becomes clogged. This product's tank top mounting configuration simplifies installation on liquid containers, while its suitability for HFC/HFA fluids broadens its application range. The Hengst model also meets DIN24550 standards, confirming its compliance with recognized industry specifications. Overall, the Hengst 10TDN1000-1X/PWR20A00-P2,2-V-S10 offers robust filtration capabilities ideal for maintaining cleanliness and efficiency in hydraulic systems.
