10TDN0630-1X/PWR10A00-P2,2-M-S9 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TDN0630-1X/PWR10A00-P2,2-M-S9 (1013173B) is a high-performance hydraulic tank-mounted return line filter designed specifically for installation on liquid containers within hydraulic or lubrication systems. This duplex filter is engineered to effectively remove solid contaminants from liquids, ensuring optimal system performance and longevity. The filter boasts a nominal size of 0630 and features a multilayer glass fiber material (PWR) as its media, providing efficient filtration with a filtration grade of 10. Constructed with an aluminum housing and standard support cage material, it is built to withstand demanding environments. The unit is equipped with an NBR seal (designated as M) and operates at a nominal pressure of 10 bar, withstanding a maximum working pressure of up to 10 bar. It also includes an optical indicator for monitoring the filter status, which activates at a switching point of 2.2 bar. The design incorporates a ball valve change-over system for ease of maintenance and reliability. This Hengst model is designed for horizontal mounting on tank tops, featuring SAE port standards with dimensions of 2 1/2'' - 3000 psi (port code S9). It also has compatibility with HFC/HFA fluids and complies with DIN24550 standards. With its robust construction capable of handling collapse pressures up to 30 bar and bypass cracking pressure set at 3.5 bar, this filter ensures dependable performance in various applications where fluid cleanliness is critical to system efficiency and protection against wear or damage from contaminants.
