10TDN0250-1X/PWR10A00-P2,2-M-R6 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TDN0250-1X/PWR10A00-P2,2-M-R6 (1013171B) is a hydraulic tank-mounted return line filter designed specifically for use in hydraulic or lubrication systems. This product is adept at filtering solid contaminants from liquids, ensuring the cleanliness and efficiency of the fluid system. The filter features a duplex design class and utilizes a multilayer glass fiber material, designated as PWR10, for its filter media. With a nominal size of 0250 and an NBR seal code, it is constructed with an aluminum housing material and supports standard support cage materials. This model is equipped with an optical indicator to alert users when maintenance is required, operating at a switching point of 2.2 bar. The tank top mounting design facilitates easy installation on liquid containers, while its port designation is G1 1/2 with horizontal positioning according to ISO228-1 standards. The maximum working pressure for this filter reaches up to 10 bar, aligning with its nominal pressure rating. Additionally, the Hengst filter supports HFC and HFA suitability and complies with DIN24550 standards. It possesses a bypass cracking pressure of 3.5 bar and a collapse pressure rating of 30 bar, ensuring reliable performance under demanding conditions. The adhesive basis used in this model is PUR-Basis, contributing to its robustness and durability in filtration tasks. With these specifications, the Hengst 10TDN0250-1X/PWR10A00-P2,2-M-R6 provides efficient filtration solutions ideal for maintaining optimal system performance in various hydraulic applications.
