$2,553.98 USD
Qty:
Delivered as early as July 17, 2026
| Collaps Pressure Code: | A |
| Design Class: | Tank mounted return line filter, duplex |
| Filter Material Configuration: | PWR10 |
| Filter Media Code: | PWR |
| Filter Media Designation: | Multilayer glass fiber material |
| Nominal Size: | 0063 |
| Seal Code: | V |
| Seal Designation: | FKM |
| Series: | 10TD |
| Support Cage Material: | Standard |
| Bypass Cracking Pressure: | 3,5 |
| Hfc Hfa Suitability: | Yes |
| Din24550: | Yes |
| Collapse Pressure Rating: | 30 bar |
| Volume: | 0.000 m³ |
| Adhesive Basis: | PUR-Basis |
| Filtration Grade: | 10 |
| Housing Material: | Aluminum / Plastic |
| Mounting: | Tank top |
| Port Code: | R4 |
| Port Designation: | G1 |
| Port Position: | Horizontal |
| Port Standard: | ISO228-1 |
| Max Working Pressure Bar: | 10 bar |
| Nominal Pressure Bar: | 10 bar |
| Indicator Existing: | No |
| Cyclone Effect: | No |
| Change Over Design: | Ball valve |
