$2,751.70 USD
Qty:
Delivered as early as May 29, 2026
| Collaps Pressure Code: | B |
| Design Class: | Manifold filter |
| Filter Material Configuration: | PWR3 |
| Filter Media Code: | PWR |
| Filter Media Designation: | Multilayer glass fiber material |
| Nominal Size: | 0400 |
| Seal Code: | V |
| Seal Designation: | FKM |
| Series: | 450PBF |
| Support Cage Material: | Standard |
| Hfc Hfa Suitability: | Yes |
| Din24550: | Yes |
| Collapse Pressure Rating: | 330 bar |
| Volume: | 0.000 m³ |
| Adhesive Basis: | PUR-Basis |
| Filtration Grade: | 3 |
| Housing Material: | Nodular Cast Iron / Carbon steel |
| Mounting: | Bottom side |
| Port Designation: | 30mm |
| Port Position: | Vertical |
| Port Standard: | Factory standard |
| Max Working Pressure Bar: | 450 bar |
| Nominal Pressure Bar: | 450 bar |
| Check Valve: | No |
| Indicator Existing: | Yes |
| 2 Parted Bowl: | No |
| Cyclone Effect: | No |
| Indicator Designation: | Optical |
| Switching Point: | 5 bar |
