HYDRAULIC GEAR PUMP AZPB-32-5.0RQR12KB-S0022

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPB-32-5.0RQR12KB-S0022 (R979107389) is an external gear pump designed for efficient conversion of mechanical energy into hydraulic energy, characterized by flow and pressure. It features a clockwise rotation and a straight shaft compliant with SAE J744 standards, ensuring compatibility with a wide range of equipment. The pump is equipped with a bolt flange according to SAE J518 AA specifications and utilizes UNB thread with SAE O-Ring ports for secure and leak-free connections. This gear pump is engineered to minimize heat losses through pressure-dependent gap sealing and high-precision manufacturing technology, which also contributes to its high efficiencies. It boasts slide bearings capable of supporting high loads, thus extending the pump's service life. With port connections that can be either flanged or threaded, it offers flexibility for various system designs. The unit's rear cover is standard, while it can operate at a maximum rotational speed defined by the product group's specifications. Its size corresponds to the geometric displacement of 5.0 cm³/rev, ensuring adequate fluid movement for a range of applications. The sealing material used is NBR for the body with an FKM shaft seal, providing durability against different types of fluids. This model comes in a corrosion-resistant version with pins and may include special versions that deviate from catalogue standards as per customer-specific requirements or drawings provided. The noise level remains within standard parameters, making it suitable for environments where noise reduction is essential. As an external gear unit, the Bosch Rexroth AZPB-32-5.0RQR12KB-S0022 functions primarily as a pump within hydraulic systems. It has an aluminum housing that contributes to its relatively light weight of 2.7 kg while being able to handle maximum intermittent pressure during operation. With a maximum flow capacity of 16 l/min, this gear pump is capable of serving various general application needs efficiently and reliably.
