HYDRAULIC GEAR PUMP AZPB-32-6.3RRR12KB

Manufacturer: Bosch Rexroth

Material #: R979107372

Model : AZPB-32-6.3RRR12KB

Destination

$265.00 USD

Availability: Backordered

Ships from US

Add to Cart

Qty:
Delivered as early as November 9, 2026

This product is eligible for factory repair.

Start Repair

HYDRAULIC GEAR PUMP AZPB-32-6.3RRR12KB

6.3 cm³/rev, Clockwise rotation, Spline shaft SAE J744 13-4 (A-A), 2-bolt flange SAE J744 50-2 (A-A), Thread UN-2B, SAE O-Ring

The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.

Unpacked Weight: 1.8 kg

Slide bearings for high loads
Long service life
Port connections: flanged or threaded
Consistent high quality based on large-volume production
Drive shafts according to ISO or SAE and customer specific solutions

Offer Drawing	Download Offer Drawing
Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Max. flow	22.1
Size (geometric displacement)	6.3
Maximum intermittent pressure	250
Maximum rotational speed	3500
Drive shaft	Spline shaft SAE J744 13-4 (A-A)
Direction of rotation	Clockwise rotation
Front cover	2-bolt flange SAE J744 50-2 (A-A)
Housing material	Aluminum
Noise level	Standard noise level
Application	general
External gear unit	External Gear Unit
External gear unit function	Pump
Series	Model B (0.84 ... 10 cm³/rev)
Unit version	Bearing diameter 12mm
Version	Corrosion resistant, pinned
Line connection	Thread UN-2B, SAE O-Ring
Sealing material	NBR, shaft seal in FKM
Rear cover	Standard
Special version	Deviations from catalogue standards, see drawing
Productgroup ID	7,21,22,23,24,25
Weight	1.8
