4WE6G2-6X/EG24N9K4/62=CSA

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6G2-6X/EG24N9K4/62=CSA (R978918127) is a high-performance solenoid-operated directional spool valve designed for controlling the start, stop, and direction of flow in hydraulic systems. This product features a robust housing, one or two electromagnets, a control spool, and return springs. The valve operates by moving the control spool from its rest position to an actuated position when the electromagnet is energized, thereby allowing fluid to flow according to the selected symbol. Once the electromagnet is de-energized, return springs push the control spool back to its initial position, except in versions with detent OF or without spring type O. The model offers manual auxiliary actuation for situations where magnetic supply is unavailable. Proper venting of the hydraulic system is essential for optimal functionality. The 4WE6G2-6X/EG24N9K4/62=CSA valve comes with various configurations including without spring return O and with detent OF options for symbols A, C, and D. It also boasts a soft switching feature that reduces switching strokes and acceleration values during operation. This specific version has a porting pattern according to ISO with options for locating holes and features a high-power solenoid which can be rotated by 90° if required. Electrical connections are versatile, offering either single or central connection possibilities. Spool position monitoring is available as an optional feature for enhanced operational awareness. The product meets CE conformity standards under the Low Voltage Directive of the EU for specified electrical voltages and has an optional UL-approved solenoid coil marking according to UL standards edition. Additionally, it holds an optional CSA approval according to CSA C22.2 No. 0-M91. It's important to note that separate return lines or check valves in drain lines are recommended due to potential pressure peaks causing unintended control spool movements in versions with detent. Moreover, internal leakage inherent in design may increase over service life; therefore, a throttle insert may be required under certain operating conditions that exceed valve performance limits.
