R978910759

4WEH 10 GA4X/6EW110N9K4

Manufacturer: Bosch Rexroth

Material #: R978910759

Model : 4WEH 10 GA4X/6EW110N9K4


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WEH 10 GA4X/6EW110N9K4 (R978910759) is a high-performance directional spool valve designed for electrohydraulic actuation, suitable for controlling the start, stop, and direction of fluid flow in various hydraulic systems. This model is part of the WEH series and is engineered for subplate mounting with porting patterns conforming to ISO standards. It is available in 2-way, 3-way, or 4-way versions and features spring or pressure centering with either spring end position or hydraulic end position. The valve's main control spool can be held in a neutral position either by return springs or through pressurization. The actuation of the pilot control valve, which includes one or two solenoids, initiates the movement of the main control spool by regulating the pilot pressure. Additionally, an optional manual override allows for manual operation without solenoid energization. This Bosch Rexroth valve also offers flexibility in terms of pilot oil supply and return configurations. It can be set up for external pilot oil supply via channel X or internal supply from channel P of the main valve. Likewise, pilot oil can be returned externally through channel Y or internally via channel T depending on the specific model configuration. The unit supports a range of optional features such as switching time adjustment, a preload valve in channel P of the main valve, stroke setting, and spool position monitoring to enhance performance and adaptability to specific application requirements. With component series X to X available, this versatile valve can handle maximum operating pressures up to bar and maximum flow rates up to l/min. For applications requiring precise control over hydraulic flow parameters within complex systems, the Bosch Rexroth 4WEH 10 GA4X/6EW110N9K4 offers reliability and customizable options that cater to a wide array of operational needs.

$1,223.00 USD

More are expected on April 7, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as April 7, 2025 when ordered in

This product is eligible for factory repair.
