CONTROL DEVICE EFC5610-2K20-3P4-MDA-7P-DRNNN-L1NN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth EFC5610-2K20-3P4-MDA-7P-DRNNN-L1NN (R912007561) is a state-of-the-art Variable Frequency Drive (VFD) designed for precise speed control and energy-efficient operation of electric motors. This VFD utilizes advanced control technologies, including V/f (Volts per frequency), Sensorless Vector Control (SVC), and Field Oriented Control (FOC), to cater to a variety of application needs. The unit's built-in brake chopper and net filter enhance its performance in applications requiring dynamic braking. With a power range of 2.2 kW, the EFC5610 series is equipped with an integrated operating panel that simplifies commissioning, allowing for quick setup and adjustments. It operates both asynchronous and synchronous motors effectively, offering flexibility for use in heavy-duty (HD) and normal-duty (ND) modes. The device's continuous power output capability ensures reliable operation under various load conditions. Safety is a paramount feature of this VFD, incorporating Safe Torque Off (STO) functionality that allows users to safely disable motor torque without removing power from the entire machine. This safety function is vital for meeting stringent safety standards in industrial environments. The EFC5610 series boasts an LED segment display with potentiometer for easy monitoring and parameter adjustment. It has an International Protection rating of IP20, signifying protection against solid objects larger than 12mm but not against liquids. The three-phase VFD can be expanded with I/O and fieldbus modules, such as ModBus interface, enhancing its connectivity and integration capabilities. Its compact design measures at a width of 100 mm, height of 200 mm, depth of 170 mm, and weighs approximately 2 kg. The supply voltage required for operation ranges from 380 V AC to 480 V AC. With these features combined, the Bosch Rexroth EFC5610-2K20-3P4-MDA-7P-DRNNN-L1NN offers robust performance in a wide array of applications where efficient motor control is critical.
