SERVOMOTOR MS2N05-B0BTN-CMSK1-NNNNN-NN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MS2N05-B0BTN-CMSK1-NNNNN-NN (R911388449) is a state-of-the-art synchronous motor designed to deliver high dynamics, compact dimensions, and superior energy efficiency. This motor is part of the MSN series and is distinguished by its self-cooling feature, which enhances its performance in various applications. The MS2N05-B0BTN-CMSK1-NNNNN-NN is equipped with rotors that offer low to medium inertia, making it an ideal choice for applications requiring precise motion control and rapid acceleration. With a continuous torque range from 0.5 to 5.4 Nm and the ability to achieve maximum torques of up to 7.1 Nm, this motor is capable of handling demanding tasks while maintaining optimal energy consumption. Its design includes a mounting hole M5, a shaft length specification for secure installation, and an IP65 international protection code that ensures durability in challenging environments. The motor's rotor inertia with brake value stands at 0.000034 kgm², while the rotor inertia without brake value is 0.000028 kgm², providing flexibility based on application requirements. The MS2N05-B0BTN-CMSK1-NNNNN-NN also features a spring-loaded shaft with seal and options for inclusion or exclusion of a holding brake depending on the need for additional stopping power. The flange size and bolt circle are designed according to standard specifications for ease of integration into existing systems. Furthermore, this model operates effectively using self-cooling or natural convection without the need for external cooling mechanisms. With a maximum speed capability and customizable features accessible through the ctrlX configurator and EPLAN platforms provided by Bosch Rexroth, users can tailor the motor to their specific needs. The weight of this unit is approximately 2.9 kg, making it lightweight yet robust enough for various industrial applications without compromising on power or efficiency.
