FIELD BUS MODULE S20-S3-BK+

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S20-S3-BK (R911173318) is a state-of-the-art IO cabinet bus coupler designed for integration within the Sercos III network, offering extended functionality for various automation applications. This device allows for the seamless connection of up to 63 participants to an existing Sercos network, facilitating communication and control within complex systems. The S20-S3-BK is characterized by its innovative assembly and installation concept that prioritizes space-saving and efficiency, making it ideal for top hat rail mounting in compact spaces. This bus coupler is part of Bosch Rexroth's modular IO technology range, which enables users to combine individual modules to create a tailored solution specific to their needs. The compact design does not compromise on capability or performance, ensuring that systems operate with reliability and precision. The model features an electronic device nameplate along with diagnostic and status indicators that contribute to ease of maintenance and troubleshooting. The S20-S3-BK is distinguished by its type code extension SSBK and falls under the Productgroup ID category for fieldbus communication protocol devices. It is configurable through the ctrlX configurator available on Bosch Rexroth's website, which aids in streamlining the setup process. Furthermore, EPLAN data for this model can be accessed through Bosch Rexroth's ECAD configuration platform, supporting efficient planning and integration into various electrical engineering projects. With its robust design and advanced technological features, the Bosch Rexroth S20-S3-BK bus coupler stands out as a vital component in modern automation systems that require a reliable fieldbus communication protocol such as Sercos III.
