$16,323.00 USD
Status: This product is temporarily out of stock.
Qty: Delivered as early as July 4, 2025 when ordered in
Through drive for mounting of further pumps up to same nominal size Optimized total efficiency Noise optimized housing Optional with charge pump for the nominal size 280 Particularly high speeds are possible with impeller pump version (A11VLO) Large variety of controls Swashplate design
|
Size |
110 | 145 | 175 | 210 | 280 | 145 | 175 | 210 | 280 | |||
|
Version |
Standard | With charge pump | ||||||||||
|
Displacement |
Vg max |
cm³ |
110 | 145 | 175 | 210 | 280 | 145 | 175 | 210 | 280 | |
|
Nominal pressure |
pnom |
bar |
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
|
Maximum pressure |
pmax |
bar |
420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | |
|
Maximum speed 1) |
at Vg max |
nnom |
rpm |
2400 | 2300 | 2150 | 2000 | 1800 | 2600 | 2500 | 2350 | 2150 |
|
Flow |
at Vg max and nnom |
qV nom |
l/min |
264 | 334 | 376 | 441 | 504 | 377 | 438 | 525 | 644 |
|
Power |
at qV nom and pnom |
P |
kW |
154 | 195 | 219 | 257 | 294 | 220 | 255 | 306 | 376 |
|
Torque |
at Vg max and pnom |
M |
Nm |
613 | 808 | 975 | 1170 | 1560 | 808 | 975 | 1170 | 1560 |
|
Weight (approx.) |
m |
kg |
64 | 79 | 97 | 111 | 143 | 92 | 110 | 125 | 148 | |
| 1) | These values are valid at an absolute pressure of 1 bar in suction port S and for the optimum viscosity range νopt |
