A A4VSO 125 DR /30R-PPB13N00 ESO527
Manufacturer: Bosch Rexroth
Material #: R902501291
Model : A A4VSO 125 DR /30R-PPB13N00 ESO527
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth A4VSO 125 DR /30R-PPB13N00 (R902501291) is a robust high-pressure axial piston pump designed for industrial applications. This pump is notable for its very long service life and low operating noise, making it an ideal choice for environments where both durability and quiet operation are valued. The unit features controls with short response times, allowing for quick adjustments and precise operation, which is essential in applications requiring meticulous hydraulic control.
The A4VSO 125 DR /30R-PPB13N00 pump also boasts excellent suction characteristics, ensuring efficient fluid intake and reliable performance under varying conditions. Its swashplate design contributes to the overall efficiency and responsiveness of the system. Furthermore, this model offers the flexibility of a through-drive configuration, permitting the mounting of additional pumps up to the same nominal size directly onto the existing unit without requiring separate drive systems.
With a size that fits a range of applications and designed to operate optimally within a nominal pressure of bar while capable of withstanding maximum pressure peaks up to bar, this pump is suited for open circuit systems. Its metric version specification ensures compatibility with standardized industrial components and systems worldwide.
Engineered with precision by Bosch Rexroth, one of the leading manufacturers in drive and control technologies, the A4VSO 125 DR /30R-PPB13N00 (R902501291) embodies reliability and performance in demanding industrial hydraulic applications.
$14,423.00 USD
More are expected on October 25, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as October 25, 2024 when ordered in
This product is eligible for factory repair.
Pressure and flow controller
DR, DP, FR, DFR
Pressure and flow controller
DR, DP, FR, DFR
Available for A4VSO and A4VSG Pressure and flow control Remote controlled optional Pressure controller for parallel operation optional Mechanical Vg min and Vg max limitationData sheet
Spare parts & repair
Power controller
LR2, LR3, LR2N, LR3N
Power controller
LR2, LR3, LR2N, LR3N
Available for A4VSO and A4VBO Precise control in accordance with the hyperbolic characteristic curve, provides an optimum utilization of available power The beginning of control is mechanically adjustable Additional functions in the modular system for pressure control, fixed setting and remotely controllable, flow control, hydraulic or mechanical stroke limiterData sheet
Spare parts & repair
Pilot-pressure related proportional control
HD
Pilot-pressure related proportional control
HD
Available for A4VSO, A4VSG and A4CSG Control is pilot-pressure related Different pilot-pressure ranges available Power control, pressure control and electrical pilot pressure supply optional Standard spring-centering of the stroking cylinderData sheet
Spare parts & repair
Electrohydraulic control systems
HSx, HMx, EOx
Electrohydraulic control systems
HSx, HMx, EOx
Available for A4VSO, A4VBO, A4VSG and A4CSG Electrohydraulic control with servo, proportional and control valve Digital electrohydraulic control systems with amplifier Control of swivel angle, pressure and power (HS5P) Usable as a special version in mooring operation (overcenter)Data sheet
Spare parts & repair
Electronic pressure and flow control
DFE1
Electronic pressure and flow control
DFE1
Available for A4VSO and A4VBO For the electrohydraulic control of pressure, flow and power Internal pilot pressure or with external control pump, optional Rapid decompression via pump by flow direction change as standard Rotary group optimized for long standby operating timesData sheet
Spare parts & repair
Secondary control for open circuit
DS2
Secondary control for open circuit
DS2
Available for A4VSO Highly dynamic rotary drive for open circuit Motor and generator operation for both directions of rotation With energy recovery and energy storage With closed loop rotational speed, position, or torque control for high control performance and dynamicsData sheet
Spare parts & repair
Pressure and flow control system
HS5E
Pressure and flow control system
HS5E
Available for A4VSO, A4VBO, A4VSG and A4CSG Electrohydraulic control systems with on-board electronics For the electrohydraulic control of pressure, flow and power Optional conversion of HS3 and HS4 to HS5EData sheet
Instruction manual
Functional description HDx20
Functional description HDx20 – Supplementary information
Parameter description
Description of diagnosis
Firmware release notes HDx20
Fact sheet
Spare parts & repair
Pressure and flow control system
SYHDFEE-1X
Pressure and flow control system
SYHDFEE-1X
Version with axial piston variable displacement pump A4VSO Size 40 … 355 Maximum operating pressure 350 bar Function: Swivel angle control, Pressure control,Torque limitation, Master-Slave Communication: Analog, configurableData sheet
Operating instructions
Environmental compatibility statement
Spare parts & repair
Pressure and flow control system
SYHDFEC-1X
Pressure and flow control system
SYHDFEC-1X
Version with axial piston variable displacement pump A4VSO Size 40 … 355 Maximum operating pressure 350 bar Function: Swivel angle control, Pressure control,Torque limitation, Master-Slave Communication: Analog, CANopen, parameterizableData sheet
Commissioning instruction
Commissioning instructions CANopen interface
Environmental compatibility statement
Spare parts & repair
Pressure and flow control system
SYHDFED-1X
Pressure and flow control system
SYHDFED-1X
Version with axial piston variable displacement pump A4VSO Size 40 … 355 Maximum operating pressure 350 bar Function: Swivel angle control, Pressure control,Torque limitation, Master-Slave Communication: Sercos, PROFINET, EtherCAT, EtherNET/IP, POWERLINK, VARAN, analogData sheet
Operating instructions
Environmental compatibility statement
Functional description HDx20
Parameter description
Description of diagnosis
Supplementary information
Spare parts & repair
Pressure and flow control system
SYHDFEn-1X
Pressure and flow control system
SYHDFEn-1X
Version with axial piston variable displacement pump A4VSO Size 40 … 355 Maximum operating pressure 350 bar Function: Swivel angle control, Pressure control, Torque limitation, Master-Slave, Variable-speed Communication: Analog, CANopen, parameterizableData sheet
Operating instructions
Environmental compatibility statement
Supplementary information
Spare parts & repair
