4WE6JA6X/EW110N9DA/B10V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6JA6X/EW110N9DA/B10V (R901499764) is a high-performance directional control valve designed for hydraulic systems that require precise control over the start, stop, and direction of fluid flow. This model features solenoid-operated directional spool valves that are essential for electromechanical operations. The valve consists of a robust housing, powerful electromagnets, a control spool, and return springs to maintain the spool in its initial position when de-energized. This particular model is engineered without spring return on the control spool, which means it does not have a defined basic position when not powered. It offers two switching positions with dual electromagnets and is capable of manual operation thanks to an auxiliary actuation feature. The hydraulic system needs proper venting to guarantee optimal functionality. The 4WE6JA6X/EW110N9DA/B10V valve is designed with soft switching characteristics that significantly reduce switching strokes and associated acceleration values, contributing to smoother operation. Users should be aware that pressure peaks in the drain line can potentially cause unintended movements of the control spool in versions with detent, so separate return lines or check valves are recommended. This Bosch Rexroth valve supports various configurations including 3- or 4-way versions with porting patterns compliant with ISO standards. It comes equipped with a high-power solenoid that can optionally be rotated by 90 degrees and offers electrical connections either as single or central connections. Spool position monitoring is an optional feature for added control precision. The valve adheres to CE conformity standards for electrical voltages above certain thresholds and includes a solenoid coil certified with UR marking according to UL specifications. Additionally, it has an optional approval according to CSA standards. For applications exceeding performance limits during switching processes, the use of a throttle insert with this valve is mandatory to manage excessive flows effectively.
