DIRECTIONAL SPOOL VALVE 3WE6A6X/EG24N9K72LQMAG24

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3WE6A6X/EG24N9K72LQMAG24 (R901471304) is a high-performance industrial hydraulic valve designed for reliable operation in various hydraulic systems. This direct-actuated spool valve features the commonly used spool symbol A, which ensures precise switching of the oil flow direction in accordance with the hydraulic symbol. It is capable of handling a maximum pressure that ensures its suitability for demanding applications. The valve is equipped with an electrical connection described as a connector pole, M12 according to EN 175301-803, inclusive of an LED and suppressor diode, with pin assignment conforming to DESINA standards. This ensures a secure and reliable electrical interface. The product belongs to Group ID 5, indicating its classification within the Bosch Rexroth product range. This model has a total of six ports and is characterized by solenoid actuation, providing responsive control over the flow. The size designation corresponds to CETOP D03, making it compatible with standard mounting interfaces. Its connection diagram adheres to NFPA T3.5.1 R2 D03 and ISO 4401 standards, ensuring its compatibility with widespread industry norms. With a supply voltage requirement of 24 VDC and two possible switching positions, this valve offers flexibility for integration into various circuit designs. It also boasts an impressive maximum flow capacity that can accommodate substantial hydraulic throughput for efficient system performance. Weighing in at just .9 kg, this unit is relatively lightweight considering its robust capabilities. The seals are made from NBR material, which provides good resistance against various types of hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC types. Overall, the Bosch Rexroth 3WE6A6X/EG24N9K72LQMAG24 valve represents a reliable solution for controlling fluid dynamics in complex hydraulic systems where performance and durability are critical.
