HY-CHECK VALVE S25A05-1X/420J3
Manufacturer: Bosch Rexroth
Material #: R901454079
Model : S25A05-1X/420J3
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S25A05-1X/420J3 (R901454079) is a high-performance industrial hydraulic seat valve designed for reliable blocking of oil flow at selected ports. This direct-actuated valve belongs to component series X and features a spool symbol A B, indicating its specific configuration and function within a hydraulic system. It is equipped to handle a maximum pressure, with an electrical connection that simplifies integration into various circuit designs.
This model boasts multiple ports and offers a maximum flow rate suitable for demanding applications. The type of connection used is a threaded connection, ensuring secure and leak-free attachment to the hydraulic system. The number of switching positions available with this valve allows for versatile operation across different settings.
With its considerable size and weight, the S25A05-1X/420J3 valve is built for durability and robust performance. It is compatible with a wide range of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR, and HFC types. This versatility ensures that it can be used in systems with diverse fluid requirements without compromising on efficiency or safety.
Moreover, the valve offers leakage-free blocking in one direction which enhances system integrity and performance. Users can also select from various cracking pressures according to their specific needs—this customization potential makes the Bosch Rexroth S25A05-1X/420J3 valve a flexible solution for many industrial applications requiring precise control over hydraulic flow.
$274.00 USD
More are expected on March 31, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 31, 2025 when ordered in
This product is eligible for factory repair.
(measured with HLP46, ϑOil = 40 ±5 °C)
∆p-qV characteristic curves with cracking pressure
Size 6
Size 8
Size 10
Size 15
Size 20
Size 25
Size 30
Without spring
With spring
With piston bore/orifice
Dimensions in mm
|
NG |
6 | 8 | 10 | 15 | 20 | 25 | 30 | |||
|
ØD1 |
mm |
22.5 | 28 | 34 | 34 | 42 | 52 | 68 | 74.5 | |
|
D2 |
G |
G1/4 | G3/8 | - | G1/2 | G3/4 | G1 | G1 1/4 | G1 1/2 | |
|
M |
M14 x 1,5 | M18 x 1,5 | - | M22 x 1.5 | M27 x 2 | M33 x 2 | M42 x 2 | M48 x 2 | ||
|
UNF/UN |
- | - | 3/4-16 UNF | 3/4-16 UNF | 1 1/6-12 UN | 1 5/16-12 UN | 1 5/8-12 UN | 1 7/8-12 UN | ||
|
L1 |
G |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 |
|
M |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 | |
|
UNF/UN |
mm |
- | - | 66 | 72 | 92 | 105 | 120 | 132 | |
|
L1 |
mm |
- | 160 1) | 168 1) | ||||||
|
L2 |
mm |
10.5 | 11.5 | 13 | 13 | 15.5 | 19 | 25 | 28 | |
|
T1 |
G |
mm |
13 | 13 | - | 15 | 18 | 19 | 22 | 22.5 |
|
M |
mm |
12 | 12 | - | 14 | 16 | 18 | 20 | 22 | |
|
UNF/UN |
mm |
- | - | 15 | 15 | 20 | 20 | 20 | 20 | |
|
SW |
G |
mm |
19 | 24 | 30 | 30 | 36 | 46 | 60 | 65 |
| 1) | Version "...A80..." |
