HY-CHECK VALVE S8A50-1X/450J3
Manufacturer: Bosch Rexroth
Material #: R901454056
Model : S8A50-1X/450J3
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S8A50-1X/450J3 (R901454056) is a high-performance industrial hydraulic seat valve designed for reliable blocking of oil flow at selected ports. This direct-actuated valve falls under component series X and features a spool symbol A B, indicating its specific configuration and operational capabilities. The S8A50-1X/450J3 is engineered to withstand a maximum pressure and is equipped with an electrical connection for seamless integration into various hydraulic systems.
With its threaded connection type, the valve offers ease of installation and maintenance, ensuring a secure fit within the system. The number of ports and switching positions are configured to meet the demands of complex hydraulic applications, while the max flow rate highlights the valve's capacity to handle significant volumes of hydraulic fluid efficiently.
The valve's compatibility with a broad range of hydraulic fluids—including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR, and HFC—underscores its versatility in various operating environments. Additionally, it boasts a feature that allows leakage-free blocking in one direction and offers various cracking pressures that can be optionally adjusted according to specific application requirements.
The S8A50-1X/450J3's robust design ensures durability and consistent performance in demanding industrial settings. Its weight has been optimized to contribute to the overall efficiency of the system without compromising on strength or reliability. Overall, this Bosch Rexroth hydraulic valve represents a reliable solution for controlling fluid dynamics in sophisticated industrial applications where precision and dependability are paramount.
$114.00 USD
More are expected on September 30, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as September 30, 2024 when ordered in
This product is eligible for factory repair.
(measured with HLP46, ϑOil = 40 ±5 °C)
∆p-qV characteristic curves with cracking pressure
Size 6
Size 8
Size 10
Size 15
Size 20
Size 25
Size 30
Without spring
With spring
With piston bore/orifice
Dimensions in mm
|
NG |
6 | 8 | 10 | 15 | 20 | 25 | 30 | |||
|
ØD1 |
mm |
22.5 | 28 | 34 | 34 | 42 | 52 | 68 | 74.5 | |
|
D2 |
G |
G1/4 | G3/8 | - | G1/2 | G3/4 | G1 | G1 1/4 | G1 1/2 | |
|
M |
M14 x 1,5 | M18 x 1,5 | - | M22 x 1.5 | M27 x 2 | M33 x 2 | M42 x 2 | M48 x 2 | ||
|
UNF/UN |
- | - | 3/4-16 UNF | 3/4-16 UNF | 1 1/6-12 UN | 1 5/16-12 UN | 1 5/8-12 UN | 1 7/8-12 UN | ||
|
L1 |
G |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 |
|
M |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 | |
|
UNF/UN |
mm |
- | - | 66 | 72 | 92 | 105 | 120 | 132 | |
|
L1 |
mm |
- | 160 1) | 168 1) | ||||||
|
L2 |
mm |
10.5 | 11.5 | 13 | 13 | 15.5 | 19 | 25 | 28 | |
|
T1 |
G |
mm |
13 | 13 | - | 15 | 18 | 19 | 22 | 22.5 |
|
M |
mm |
12 | 12 | - | 14 | 16 | 18 | 20 | 22 | |
|
UNF/UN |
mm |
- | - | 15 | 15 | 20 | 20 | 20 | 20 | |
|
SW |
G |
mm |
19 | 24 | 30 | 30 | 36 | 46 | 60 | 65 |
| 1) | Version "...A80..." |
