HY-CHECK VALVE S8A05-1X/450J3
Manufacturer: Bosch Rexroth
Material #: R901454052
Model : S8A05-1X/450J3
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S8A05-1X/450J3 (R901454052) is a high-performance industrial hydraulic seat valve known for its reliable blocking of oil flow at selected ports. This direct actuated valve is part of component series X and features the spool symbol A B, indicating its specific operational characteristics. It is designed to handle a maximum pressure, with an electrical connection that simplifies integration into various hydraulic systems. The product group ID and number of ports are specified to ensure compatibility and functionality for the intended applications.
The S8A05-1X/450J3 valve boasts a size that accommodates a significant max flow rate, making it suitable for systems requiring robust fluid control. It offers a threaded connection type, ensuring secure and leak-free installation into existing setups. With multiple switching positions available, this valve can adapt to different operational needs within the hydraulic circuit.
Weighing in at an efficient mass, the S8A05-1X/450J3 does not add excessive weight to machinery, maintaining overall equipment efficiency. It is compatible with a wide range of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR, and HFC types. This compatibility ensures versatility across different systems and operational requirements.
Additionally, this Bosch Rexroth valve offers leakage-free blocking in one direction and comes with options for various cracking pressures to suit different application needs. The maximum operating pressure (bar) and maximum flow (l/min) specifications highlight the valve's capacity to function under demanding conditions. Its threaded connection screw-in thread design ensures that installation is straightforward and secure for industrial hydraulics professionals seeking reliable performance in their fluid power applications.
$114.00 USD
More are expected on September 19, 2024
Status: This product is temporarily out of stock.
Qty: Delivered as early as September 19, 2024 when ordered in
This product is eligible for factory repair.
(measured with HLP46, ϑOil = 40 ±5 °C)
∆p-qV characteristic curves with cracking pressure
Size 6
Size 8
Size 10
Size 15
Size 20
Size 25
Size 30
Without spring
With spring
With piston bore/orifice
Dimensions in mm
|
NG |
6 | 8 | 10 | 15 | 20 | 25 | 30 | |||
|
ØD1 |
mm |
22.5 | 28 | 34 | 34 | 42 | 52 | 68 | 74.5 | |
|
D2 |
G |
G1/4 | G3/8 | - | G1/2 | G3/4 | G1 | G1 1/4 | G1 1/2 | |
|
M |
M14 x 1,5 | M18 x 1,5 | - | M22 x 1.5 | M27 x 2 | M33 x 2 | M42 x 2 | M48 x 2 | ||
|
UNF/UN |
- | - | 3/4-16 UNF | 3/4-16 UNF | 1 1/6-12 UN | 1 5/16-12 UN | 1 5/8-12 UN | 1 7/8-12 UN | ||
|
L1 |
G |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 |
|
M |
mm |
58 | 58 | - | 72 | 88 | 98 | 120 | 132 | |
|
UNF/UN |
mm |
- | - | 66 | 72 | 92 | 105 | 120 | 132 | |
|
L1 |
mm |
- | 160 1) | 168 1) | ||||||
|
L2 |
mm |
10.5 | 11.5 | 13 | 13 | 15.5 | 19 | 25 | 28 | |
|
T1 |
G |
mm |
13 | 13 | - | 15 | 18 | 19 | 22 | 22.5 |
|
M |
mm |
12 | 12 | - | 14 | 16 | 18 | 20 | 22 | |
|
UNF/UN |
mm |
- | - | 15 | 15 | 20 | 20 | 20 | 20 | |
|
SW |
G |
mm |
19 | 24 | 30 | 30 | 36 | 46 | 60 | 65 |
| 1) | Version "...A80..." |
