4WRPDH6C1B40L-2X/M/24ED6T

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPDH6C1B40L-2X/M/24ED6T (R901416340) is a state-of-the-art directional control valve with an integrated digital axis controller designed for high-precision hydraulic control applications. This advanced valve combines position, pressure/force, closed-loop speed, and flow control capabilities with the convenience of Ethernet connectivity for easy integration into modern industrial systems. Featuring a direct-operated control spool and sleeve in servo quality, the valve ensures best-in-class response sensitivity with minimal hysteresis, providing precise control for demanding applications. The integrated IAC Multi-Ethernet electronics offer multiple interface options including analog/digital interfaces (XH), Ethernet interfaces (XE), and sensor interfaces both analog (XM) and digital (XM). This flexibility allows for versatile operation modes such as valve direct control, drive-controlled position control, positioning block operation, and more. The 4WRPDH6C1B40L-2X/M/24ED6T ensures comprehensive monitoring capabilities with functions that detect undervoltage conditions, communication errors, cable breaks, short circuits, microcontroller watchdog issues, and electronics temperature. These features are critical for maintaining system integrity and preventing costly downtime. For safety-critical applications, the internal safety function of the valve can be utilized up to category PL e according to EN ISO 13849-1. It provides channel shutoff in compliance with EN standards ensuring operational security in P to A direction—though it should be noted that switching off direction P to B is not possible in a safety-relevant manner according to EN depending on the valve type. To facilitate project planning, parameterization, commissioning, and diagnostics tasks efficiently, users can employ the IndraWorks DS engineering tool. This PC-based program supports various Windows operating systems and offers a user-friendly interface to manage all data related to the IAC Multi-Ethernet valves. In summary, the Bosch Rexroth 4WRPDH6C1B40L-2X/M/24ED6T is an intelligent hydraulic solution that brings together precision engineering with advanced electronic controls suitable for a wide range of industrial applications requiring exacting fluid power management.
