PRESSURE REDUCING VALVE DRE20-6X/100YMG24K4V
Manufacturer: Bosch Rexroth
Material #: R901411633
Model : DRE20-6X/100YMG24K4V
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DRE20-6X/100YMG24K4V (R901411633) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a set command value. This valve features a spool symbol B A and is capable of handling a maximum pressure with an electrical connection described by Connector polePE according to DINEN standards. It is equipped with an electrical actuation requiring external electronics, and the size of the electrical connector is Connector pole PE. The DRE20-6X/100YMG24K4V offers subplate mounting, conforming to CETOP D connection diagram ISO standards, and operates on a supply voltage of 24 VDC.
This model has been engineered for precise operation with its proportional solenoid ensuring linearized pressure-command value characteristic curves and good transient response. The valve allows for optional configurations, such as the addition of a check valve between ports A and B or a maximum pressure limitation feature for safety purposes. The device's seals are made from FKM material which supports various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, and HFDR.
The Bosch Rexroth DRE20-6X/100YMG24K4V valve operates by reducing the pressure in channel A in response to the command value dependent on the proportional solenoid's position. In its resting state when there's no pressure in channel B, an integrated spring maintains the main spool in its initial position to prevent startup jumps. When activated, the main spool adjusts to balance forces once the preset pressure in channel A is achieved.
With its robust design and advanced functionality, this valve ensures stable and controlled operation within hydraulic systems where reducing system pressure is required. It can support a maximum operating flow rate and comes from component series X. The third way from A to Y measures . mm ensuring efficient flow control within hydraulic circuits.
$3,290.00 USD
More are expected on June 9, 2025
Status: This product is temporarily out of stock.
