Spool symbol | Symbol W6 |
Max. pressure | 270 |
Electrical connection description | Connector 7-pole (6 + PE) according to EN 175201-804 |
Productgroup ID | 9,10,11,12,13,14 |
Number of ports | 4 |
Type of actuation | Electrical with integrated electronics |
Conformity description | CE – electromagnetic compatibility 2014/30/EU RoHS Directive 2011/65/EU REACH Regulation (EC) no. 1907/2006 |
Size | 27 |
Electrical connector | Connector 7-pole (6 + PE) |
Max. flow | 1850 |
Type of connection | Subplate mounting |
Connection diagram NFPA | NFPA T3.5.1 R2-2002 D08 |
Size_CETOP | D08 |
Nominal flow | 430 |
Supply voltage | 24 VDC |
Number of switching positions | 3 |
Weight | 20.800 |
Seals | NBR |
Connectivity | Analog, command value ±10 V |
Hydraulic fluid | HL,HLP,HFC (Fuchs: Hydrotherm 46M, Renosafe 500; Petrofer: Ultra Safe 620; Houghton: Safe 620; Union: Carbide HP5046) |
Conformity | CE,RoHS |
Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
Conformity | CE |
