PRESSURE RELIEF VALVE -Z ZDB6VP2-4X/315/60

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDB6VP2-4X/315/60 (R901397224) is a pilot-operated pressure relief valve designed for sandwich plate mounting, providing precise control for limiting system pressure. This valve is engineered to maintain stability and performance within hydraulic systems by utilizing one or two pressure valve cartridges housed within its robust construction. The system's pressure can be finely tuned through various adjustment types, ensuring tailored responsiveness to specific operational requirements. In its default state, the ZDB6VP2-4X/315/60 valve remains closed until the pressure in channel A overcomes the pre-set spring value, triggering the pilot poppet to open and allowing hydraulic fluid to flow from A to T. This action balances the system pressure according to the settings applied via the spring mechanism. The pilot oil drainage from spring chambers is managed externally through channel T, contributing to a streamlined and efficient operation. Designed with versatility in mind, this valve features a porting pattern that complies with ISO standards and offers multiple circuit options. It can be equipped with either one or two pressure valve cartridges based on application needs. To accommodate various user preferences and ensure secure settings, Bosch Rexroth provides several adjustment types for this model including a rotary knob, a sleeve with hexagon and protective cap, a lockable rotary knob with scale, or a simple rotary knob with scale. Furthermore, this model boasts a corrosion-protected design that enhances its durability in harsh working environments. Whether it's component side or plate side mounting requirements, the ZDB6VP2-4X/315/60 adapts seamlessly into different hydraulic systems making it an essential component for industrial applications requiring precise pressure relief functions.
