PROPORTIONAL DIRECTIONAL VALVE 4WRPEH6C3B12L-3X/V/24F1

Manufacturer: Bosch Rexroth

Material #: R901382513

Model : 4WRPEH6C3B12L-3X/V/24F1

Destination

$7,513.50 USD

Availability: Backordered

Ships from US

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as February 9, 2027

$7,889.18 USD

Availability: Backordered

Ships from CA

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as February 9, 2027

PROPORTIONAL DIRECTIONAL VALVE 4WRPEH6C3B12L-3X/V/24F1

Size 6, symbol C3, electrical with integrated electronics 24 V DC

Industrial hydraulic valve in a high performance range. Reliable control of the oil flow direction according to hydraulic symbol. High accuracy thanks to internal piston position feedback

Unpacked Weight: 2.98 kg

Safety shut-down with additional fail-safe position
Spool valve
Direct actuated
Component series 3X
Size 6
Rated flow 4 … 40 l/min
Digital interface, IO-Link for I4.0
Maximum operating pressure 350 bar

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Connection diagram	ISO 4401-03-02-0-05
Max. pressure	350
Max. flow	22
Spool symbol	Symbol C3
Type of connection	Subplate mounting
Nominal flow	12
Size	6
Type of actuation	Electrical with integrated electronics
Number of ports	4
Number of switching positions	4
Supply voltage	24 VDC
Electrical connector	Connector 7-pole (6 + PE)
Electrical connection description	Connector 7-pole (6 + PE) according to EN 175201-804
Connectivity	Analog, command value 4 … 20 mA
Conformity description	CE – electromagnetic compatibility 2014/30/EU RoHS Directive 2011/65/EU REACH Regulation (EC) no. 1907/2006
Conformity	CE,RoHS
Hydraulic fluid	HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR
Seals	FKM
Connection diagram NFPA	NFPA T3.5.1 R2-2002 D03
Size_CETOP	D03
Productgroup ID	9,10,11,12,13,14
Weight	2.98
