PRESSURE TRANSDUCER HM 20-2X/160-H-K35-N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HM 20-2X/160-H-K35-N (R901381347) is a high-performance pressure transducer designed for dynamic pressure control in hydraulic systems. This transducer features an analog output of 0.5...4.5 V, with a pressure range up to 160 bar, and is equipped with a G1/4 hydraulic connection. The short signal rise time of less than 10 ms ensures rapid response times for demanding applications. The HM 20-2X/160-H-K35-N offers a high degree of measurement accuracy, less than ±0.25% of Full Scale (FS), and boasts excellent overload and bursting behavior, which contributes to operational safety and reliability. The thin-film measuring cell technology within the sensor provides precise measurements, while the stainless steel components that come into contact with media ensure durability and resistance to corrosive fluids. This model is designed without a display and is powered by a supply voltage of 9...32 VDC. It has a weight of approximately 0.2 kg and uses NBR seals for compatibility with hydraulic fluids such as HL, HLP, HFC, and Nitrogen up to 160 bar. The electrical connector is an M12x1 A-coded according to EN standards. With its robust construction and comprehensive protection features including reversed polarity, overvoltage, and short-circuit protection, the HM 20-2X/160-H-K35-N maintains performance across a wide operating temperature range from -40°C to +125°C. It also holds marine approval DNVGL for all variants with current output signaling its suitability for marine applications. Designed to offer both precision and durability, this pressure transducer from Bosch Rexroth meets CE standards for electromagnetic compatibility along with UL certification and RoHS compliance, reflecting its adherence to international safety and environmental regulations.
