DIRECTIONAL SPOOL VALVE 4WE6D6X/OEW110RN9DK6L/62
Manufacturer: Bosch Rexroth
Material #: R901356645
Model : 4WE6D6X/OEW110RN9DK6L/62
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6D6X/OEW110RN9DK6L/62 (R901356645) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction in accordance with hydraulic symbol D. This direct-actuated spool valve is characterized by its robust construction and precision in controlling the start, stop, and direction of fluid flow. It features a size 6 CETOP interface, with a maximum pressure capacity and an electrical connection via a connector pole PE according to EN, including an LED indicator.
Equipped with two solenoid actuators for robust performance, the 4WE6D6X/OEW110RN9DK6L/62 offers a max. flow rate that ensures efficient operation across various applications. The valve operates on a supply voltage of 110 VAC with a rectifier and has two switching positions for versatility in system integration. Its weight is optimized for its size and capabilities.
The spool valve's seals are made from NBR, compatible with hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. It conforms to CE standards under the Low Voltage Directive EU for electrical safety and reliability. Additionally, it includes CSA approval according to CSA C22.2 No. 0-M91.
This model comes without spring return (type O), suitable for symbols A, C, and D configurations. It supports both 3-way or 4-way versions with porting patterns according to ISO standard. The high-power solenoid is optionally rotatable by 90 degrees providing flexibility in mounting orientations.
Optional features include an auxiliary operating device for manual control without power supply and spool position monitoring for enhanced operational awareness. The solenoid coil comes with UR marking according to UL standard edition optional and may also have an optional approval according to CSA standards.
The Bosch Rexroth 4WE6D6X/OEW110RN9DK6L/62 valve is thus engineered to meet demanding industrial requirements offering reliable performance under various operating conditions while maintaining energy efficiency through its design that allows reduced current supply during operation when equipped with detent OF option.
$614.00 USD
More are expected on November 6, 2025
Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.Qty | Price | Savings |
---|---|---|
5+ | $598.65 USD | $15.35 USD |
Status: This product is temporarily out of stock.
Qty: Delivered as early as November 6, 2025 when ordered in
