PROPORTIONAL DIRECTIONAL VALVE 4WREE6E1-32-2X/G24K31/F1M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WREE6E1-32-2X/G24K31/F1M (R901354735) is a state-of-the-art industrial hydraulic valve that offers precise control over oil flow direction and magnitude. This direct-actuated spool valve features a spool symbol E, designed for subplate mounting with porting patterns conforming to ISO standards. It is equipped with integrated electronics and electrical position feedback, ensuring high accuracy and reliable performance in controlling hydraulic systems. The valve's structure includes a robust housing, a control spool with compression springs, solenoids with central threads, a position transducer, integrated electronics for signal processing, and an accessible electrical zero-point adjustment. With its analog connectivity accepting command values in the range of 4-20 mA and operating on a supply voltage of 24 VDC, this hydraulic valve is well-suited for sophisticated industrial applications requiring precise fluid control. The 4WREE6E1-32-2X/G24K31/F1M has been engineered to handle a maximum pressure and offers nominal flow rates consistent with its CETOP D size designation. The number of ports and switching positions facilitate versatile system integration. Designed for durability, it includes NBR seals that are compatible with various hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. This high-performance valve operates by actuating the control spool via proportional solenoids which are controlled by the integrated electronic unit based on the input signal received. The spring-centered control spool ensures that the valve returns to its central position when deenergized. This feature allows for safe operation even during power loss or system shutdowns. Bosch Rexroth's commitment to quality is evident in this product's design which incorporates features aimed at extending service life and minimizing internal leakage over time. It is critical to maintain proper installation conditions as specified by the manufacturer to ensure optimal functioning of this advanced hydraulic component.
