PROP PRESSURE CONTROL VALVE -Z ZDBEE6VP2-2X/315G24K31A1M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDBEE6VP2-2X/315G24K31A1M (R901335463) is a high-performance industrial hydraulic valve designed for reliable pressure limitation in accordance with a command value signal. This pilot-operated proportional pressure relief valve is characterized by its electrical actuation with integrated electronics, making it suitable for sophisticated hydraulic control systems. It operates with a maximum pressure rating of 315 bar, and features a spool symbol P T for efficient flow direction. The valve's size conforms to CETOP D standards and has an ISO 4401 porting pattern, ensuring compatibility with various mounting styles such as subplate and sandwich plate connections. The electrical connection is facilitated through a Connector pole + PE according to EN 175301-803 standards, which provides secure and stable connectivity. Equipped with an analog command value input ranging from 0 to 10 V, the ZDBEE6VP2-2X/315G24K31A1M allows for precise control over hydraulic fluid pressures. It is compatible with several types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. The valve also meets CE conformity requirements for electromagnetic compatibility within the EU. This model incorporates a proportional solenoid that translates electric current into mechanical force to adjust the system pressure seamlessly. The design ensures that as the electric current increases or decreases, so does the solenoid force and consequently the system pressure. The valve's linear pressure-command value characteristic curve allows for accurate setting of pressures without significant hysteresis. For installation purposes, it's important to ensure that tank lines are not allowed to run empty and if necessary, install a preload valve with approximately 5 bar preload pressure. This ensures optimal operation and longevity of the Bosch Rexroth ZDBEE6VP2-2X/315G24K31A1M valve in various industrial applications where precise pressure control is critical.
