PRESSURE REDUCING VALVE DREM10-6X/100YMG24-8K4M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DREM10-6X/100YMG24-8K4M (R901335080) is a high-performance industrial hydraulic valve designed for reliable pressure reduction in accordance with the command value signal. This CETOP D size valve features a spool symbol BA and is capable of handling a maximum pressure with an electrical connection via a Connector pole PE according to DIN EN. It has multiple ports, utilizes electrical actuation with external electronics, and can achieve a max flow rate. The subplate mounting type of connection complies with ISO standards, and the valve operates on a 24 VDC supply voltage. The DREM10-6X/100YMG24-8K4M is primarily used for pilot-operated pressure reduction through its proportional solenoid and main valve mechanism, which includes an optional check valve. The pressure in channel A is adjusted by the proportional solenoid, while the main spool regulates the flow between channels B and A to maintain the desired pressure level. A spring-loaded pressure relief valve can be optionally installed as a safety feature to prevent excessive pressures. This model exhibits linearized pressure-command value characteristics for precise control and boasts excellent transient response capabilities. It's compatible with hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. The seals are made from NBR to ensure durability under various operating conditions. Moreover, an optional check valve can be incorporated between ports A and B for enhanced functionality. With its robust design and advanced features like optional maximum pressure limitation and third-way functionality from A to Y measuring 0.3 mm, the Bosch Rexroth DREM10-6X/100YMG24-8K4M offers reliable performance in hydraulic systems requiring precise pressure modulation.
