Z1S6T05-4X/N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z1S6T05-4X/N (R901312739) is a high-quality direct operated check valve designed for efficient hydraulic control in various applications. This sandwich plate valve ensures leak-free blocking in one direction while permitting free flow in the opposite, making it an essential component for systems requiring precise fluid control. The valve features a stroke limitation for the poppet via a plastic socket, ensuring consistent operation and preventing over-travel. A spring mechanism aids in the closing movement of the poppet and maintains it in a closed position when the valve is inactive. The versatility of this model is highlighted by its ability to function both as an angle valve, which can link or close off up to three internal channels, and as a straight-through valve section. The plug screw within the valve takes on stop and sealing functions, contributing to its overall reliability and performance. For installations where the blue plastic socket faces the plate side, no additional seal ring is necessary, streamlining assembly processes. Constructed with corrosion-protected materials and featuring a poppet made from high-performance plastic, this Bosch Rexroth check valve guarantees perfect leaktightness even under demanding conditions. Its porting pattern conforms to ISO standards, offering compatibility with various hydraulic systems. Additionally, users can easily adapt the valve to special hydraulic fluids by simply exchanging external seal rings. Optional features include measuring ports for monitoring system performance and the ability to request this model as a throttle check valve. The Bosch Rexroth Z1S6T05-4X/N is suitable for vertical stacking applications and excels in providing reliable one- and two-channel blocking functions within hydraulic circuits.
