M-3SED6CK1X/350CG24N9XNK4/V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth M-3SED6CK1X/350CG24N9XNK4/V (R901271232) is a direct operated directional seat valve with solenoid actuation, designed to control the start, stop, and direction of fluid flow within hydraulic systems. This model features a manual override for valve switching without solenoid energization and is pressure-compensated for consistent operation. The valve's initial position can be either normally open or normally closed, determined by the spring arrangement. Constructed with a durable housing, solenoid, valve seats, and a control spool, the M-3SED6CK1X/350CG24N9XNK4/V ensures reliable performance in controlling fluid flow. It can handle maximum operating pressures with ease and allows for bidirectional flow regulation. In its default state, the control spool is held against its seat by a spring to block flow; when activated by the solenoid, it shifts to allow passage. This model includes a throttle insert option for scenarios where operational conditions may lead to flows exceeding the valve's performance limit during switching processes. Additionally, it features an innovative Plus plate beneath the directional seat valve that enhances functionality by providing alternate connection configurations during various operational states. The Bosch Rexroth M-3SED6CK1X/350CG24N9XNK4/V conforms to ISO porting patterns (excluding locating hole) and offers wet-pin DC solenoids that ensure safe switching even after extended periods under pressure. The solenoid coil can be rotated by 90 degrees for flexible installation orientations. Electrical connections are made via individual connections and there's an option for manual override if needed. This versatility makes it suitable for various hydraulic applications requiring precise control over fluid dynamics without sacrificing performance or reliability.
