DIRECTIONAL SPOOL VALVE Z4WEH22E63-5X/6EG24N9ETK4QMAG24/B10

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z4WEH22E63-5X/6EG24N9ETK4QMAG24/B10 (R901252975) is a high-performance directional spool valve with electrohydraulic actuation. It is designed to function as both a shutoff valve and a shutoff short-circuit through valve, providing versatility in controlling the flow of hydraulic fluid in complex systems. This model allows for free flow from ports P to T in every spool position, ensuring consistent operation across various applications. The valve features porting patterns that adhere to ISO standards for ease of integration into existing hydraulic systems. It can be equipped with either wet-pin DC or AC solenoids based on user requirements, offering flexibility in electrical control options. Additionally, the option for an auxiliary operating device with individual electrical connections is available, with central connections provided upon request. For precise control over hydraulic operations, this model includes optional features such as switching time adjustment and stroke setting at the main spool. The ability to fine-tune these settings allows for smoother transitions and more accurate positioning of the spool during use. Moreover, the Z4WEH22E63-5X/6EG24N9ETK4QMAG24/B10 can be fitted with inductive position switches and proximity sensors for contactless detection of spool position, enhancing the reliability and safety of the system it is integrated into. Overall, this Bosch Rexroth directional spool valve stands out for its adaptability and precision control capabilities, making it suitable for a wide range of electrohydraulic applications where dependable performance is critical.
