DR30-5-5X/200-100YMV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR30-5-5X/200-100YMV (R901201341) is a sophisticated pilot-operated pressure reducing valve designed to effectively manage and reduce hydraulic pressure in a controlled manner. This valve operates by allowing hydraulic fluid to flow from channel B to channel A without restriction when in the rest position. The innovative design includes a main valve with a spool insert and a pilot control valve equipped with a pressure adjustment element, ensuring precise pressure modulation according to the requirements of the secondary circuit. The functionality of the DR30-5-5X/200-100YMV is based on achieving equilibrium between the pressure in channel A and the spring-set value, which determines the reduced pressure level. The valve ensures that this balance is maintained, thus providing stable operation. An external pilot oil return via control line ensures efficiency and proper functioning of the system. This model also offers flexibility for installation with options for subplate mounting, threaded connections, or as a cartridge valve. It adheres to ISO porting patterns, ensuring compatibility with standard systems. Users can select from various adjustment types for optimal control, including a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale based on their specific needs. For enhanced monitoring capabilities, there's an integrated pressure gauge connection that allows users to verify the reduced pressure in channel A easily. Additionally, an optional check valve can be installed for free return flow from channel A to B but is only available for subplate mounting configurations. The Bosch Rexroth DR30-5-5X/200-100YMV represents precision engineering designed to deliver reliable performance in reducing hydraulic pressures within diverse applications while offering customization through its adjustable features and installation options.
