DR20-5-5X/315-175YMV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR20-5-5X/315-175YMV (R901201336) is a high-performance pressure reducing valve that operates on a pilot-controlled mechanism, ensuring precise pressure modulation in hydraulic systems. This valve is specifically designed for secondary circuit control and features a main valve with a spool insert and a pilot control valve equipped with an adjustable pressure element. The DR20-5-5X/315-175YMV allows free flow from channel B to A when in the rest position, with the system's pressure balancing against an adjustable spring in the pilot control valve to maintain desired pressure levels. This model is adept at maintaining stability in hydraulic pressure, which is crucial for applications requiring consistent force or speed. The external pilot oil return ensures efficient operation by directing fluid back into the tank via a control line. Additionally, for applications necessitating reverse flow, an optional check valve can be integrated when mounted on a subplate. The Bosch Rexroth DR20 series offers various adjustment types to cater to different operational preferences, including rotary knobs and lockable versions with scales for precision settings. The DR20-5-5X/315-175YMV also comes with a porting pattern compliant with ISO standards, making it versatile for subplate mounting or threaded connections. Furthermore, it can be used as a cartridge valve if required. A notable feature of this model is the presence of a pressure gauge connection that facilitates monitoring of the reduced pressure in channel A, ensuring that users can easily verify system performance. Built to deliver reliable and efficient performance, the Bosch Rexroth DR20-5-5X/315-175YMV valve stands out as an essential component for advanced hydraulic systems requiring controlled pressure reduction.
