R901170487

Z1FG6P8-4X/V

Manufacturer: Bosch Rexroth

Material #: R901170487

Model : Z1FG6P8-4X/V


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z1FG6P8-4X/V (R901170487) is a throttle valve designed for precise flow limitation within hydraulic systems. This sandwich plate valve, part of the ZFG series, is engineered to control fluid flow in channel P by utilizing a throttling point created between the control edge and the throttle spool. Users can finely tune the flow rate through this channel by adjusting the axial position of the throttle spool using a spindle mechanism. The adjustment stroke of the spindle is securely limited in both directions by a pin, ensuring stable operation within predefined limits. The Z1FG6P8-4X/V valve boasts compatibility with ISO porting patterns and includes a locating hole for ease of installation. It is designed to be mounted between components or onto a plate side, providing versatility for integration into various hydraulic circuits. The valve is equipped with a spindle featuring a hexagon socket for adjustments, allowing technicians to set desired flow rates accurately. This model from Bosch Rexroth supports maximum operating pressures up to X bar and can handle maximum flow rates of l/min, making it suitable for a wide range of applications that require reliable and consistent flow regulation. Its robust construction and precision engineering are indicative of Bosch Rexroth's commitment to quality in hydraulic system components. With its ability to limit flow in a controlled manner, the Z1FG6P8-4X/V valve is an essential part for systems where maintaining specific fluid dynamics is critical for optimal performance.

$505.00 USD

Availability:  5  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as November 25, 2024 when ordered in

This product is eligible for factory repair.
