DBW10B2-5X/315S6EG24N9K4R10E

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBW10B2-5X/315S6EG24N9K4R10E (R901162400) is a high-performance pilot-operated pressure relief valve designed for effective operating pressure limitation and solenoid-actuated unloading. This valve is composed of a main valve with a spool insert and a pilot control valve that includes a pressure adjustment element, along with an integrated directional spool valve. It functions similarly to the DB type valve, but unloading of the main spool is executed through the control of the attached directional spool valve. One of the key features of this model is its switching shock damping sandwich plate variant, which significantly mitigates pressure peaks and acoustic decompression shocks in return lines by delaying the opening from port B to B. This is achieved via a switching shock damping valve positioned between the pilot control valve and the directional valve. The level of decompression shock damping can be adjusted through various nozzle sizes, with the R code nozzle being recommended. The DBW10B2-5X/315S6EG24N9K4R10E offers flexibility in installation, as it can be mounted on subplates with porting patterns conforming to ISO standards NG6, NG10, and NG16 or used as a screw-in cartridge valve. Users have several options for setting pressure adjustments including a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. For operations requiring solenoid-operated unloading, this model can perform efficiently through its built-on directional spool or poppet valves. It also features high-power solenoids for robust performance. Additionally, this model includes optional switching shock damping for enhanced system protection against abrupt pressure changes.
