PRESSURE RELIEF VALVE DBDS 30 K1X/315 SO157

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBDS 30 K1X/315 (R901154726) is a high-performance industrial hydraulic screw-in cartridge valve designed for reliable pressure limitation to a set value. This direct operated pressure relief valve falls under the DBD.K product family and is suitable for a maximum operating pressure of 315 bar (4568 psi) and can handle a maximum flow of 30 l/min (7.93 gpm). The valve features a cavity Mx for installation and utilizes NBR sealing material, ensuring compatibility with hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. The DBDS 30 K1X/315 is engineered with a poppet type seat to maintain system pressure within desired parameters. It includes an adjustment mechanism that can be configured using various options like a bushing with hexagon and protective cap, allowing for precise control over pressure settings. The unit's construction ensures that the adjustment element remains movable within the adjustment type even when fully unloaded. This product is characterized by its robust design including sleeve, spring, poppet with damping piston for bar configurations or ball for bar configurations. Its functionality involves channel P being connected to the system where the system pressure acts on the poppet surface or ball. When this pressure exceeds the spring's set value, the poppet or ball opens against the spring force allowing fluid to flow from channel P to T. Bosch Rexroth has divided the entire pressure range into different ratings corresponding to specific springs tailored for varying maximum operating pressures. This valve's design prevents loss of adjustment capability and includes safeguards against unintended adjustments. Options for mounting include threaded connection or subplate mounting, providing flexibility in application across various hydraulic systems without compromising on performance or safety.
