$3,210.00 USD
Status: This product is temporarily out of stock.
Qty: Delivered as early as October 10, 2024 when ordered in
| With concealed manual override: With concealed auxiliary actuation |
| Seat valve |
| Direct actuated |
| Maximum flow 25 l/min |
| Component series 3X |
| Size 6 |
| Maximum operating pressure 420 / 630 bar |
| Data Sheet | Download Data Sheet |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Spool symbol | Symbol C |
| Max. pressure | 420 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Productgroup ID | 9,10,11,12,13,14 |
| Number of ports | 3 |
| Type of actuation | with solenoid actuation |
| Size | 6 |
| Electrical connector | Connector 3-pole (2 + PE) |
| Max. flow | 25 |
| Type of connection | Subplate mounting |
| Connection diagram NFPA | NFPA T3.5.1 R2-2002 D03 |
| Size_CETOP | D03 |
| Connection diagram | ISO 4401-03-02-0-05 |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Weight | 1.720 |
| Seals | NBR |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
