DR6DP3-5X/160YMV/60

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP3-5X/160YMV/60 (R901139017) is a direct operated pressure reducing valve designed for subplate mounting and is part of the component series X. This model is engineered to limit system pressure by setting the secondary pressure via an adjustment type, ensuring consistent performance in hydraulic systems. The valve's initial open position allows for unrestricted flow from channel P to channel A, while the secondary circuit's pressure limitation is managed through a control spool actuated by a compression spring. In operation, hydraulic fluid can flow freely until the set pressure is exceeded, at which point the control spool moves to maintain a constant level in channel A. Any external force that increases pressure in channel A further compresses the spring and connects channel A to channel TY through the control edge on the spool, allowing excess fluid to discharge into the tank and preventing significant pressure rise. Notably, signal and pilot oil are internally sourced from channel A via a control line. The valve features leakage oil discharge from its spring chamber externally through channel TY. For reverse flow from channel A back to channel P, an optional check valve can be installed. The DR6DP3-5X/160YMV/60 also includes a pressure gauge connection for monitoring secondary pressure. It offers various adjustment types such as rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. The porting pattern is compliant with DIN form A and ISO standards with an optional locating hole. With its robust design, this Bosch Rexroth valve ensures reliable regulation of system pressures up to its maximum operating capacity of 160 bar and supports maximum flow rates as specified for this model size and series. It is ideal for applications requiring precise control over secondary circuit pressures within hydraulic systems.
