DR6DP2-5X/80YMV/60

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP2-5X/80YMV/60 (R901139003) is a high-performance direct operated pressure reducing valve designed for subplate mounting with porting patterns conforming to DIN form A and ISO standards, including an optional locating hole. It features a robust way version mechanism that limits the secondary circuit system pressure through precise adjustments made via the adjustment type. In its initial position, this valve allows unrestricted hydraulic fluid flow from channel P to channel A, while simultaneously maintaining the set pressure in channel A constant through the action of a compression spring and control spool. The DR6DP2-5X/80YMV/60 valve ensures internal signal and pilot oil are directed via the control line from channel A, with external forces influencing actuator pressure being compensated by further movement of the control spool against the spring. This action connects channel A to channel TY through a control edge on the spool, allowing excess hydraulic fluid to discharge into the tank and maintain a stable pressure level. Leakage oil from the spring chamber is discharged externally through channel TY. An optional check valve can be installed for free flow back from channel A to P, enhancing versatility. Additionally, a pressure gauge connection enables monitoring of secondary pressure. This model offers various adjustment types for different applications: rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. It comes in size component series X and can handle maximum operating pressures up to bar levels with maximum flow rates measured in liters per minute. The inclusion of an optional check valve further extends its application range. The Bosch Rexroth DR6DP2-5X/80YMV/60 is engineered for reliability and precise control in hydraulic systems requiring consistent secondary pressure regulation.
