HED 8 OP-2X/50K14KW SO16

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HED 8 OP-2X/50K14KW SO16 (R901106446) is a high-quality hydroelectric pressure switch designed for precision monitoring and control of hydraulic pressure within a system. This piston type pressure switch features a robust housing, an installation kit that includes a piston, compression spring, adjustment element, and a micro switch for reliable operation. When the monitored pressure falls below the set value, the micro switch is activated, either initiating or interrupting an electric circuit based on the system's configuration. The piston is influenced by the incoming pressure and counteracted by the adjustable compression spring force. Movement of the piston is conveyed to the micro switch through a spring plate, which also serves as a mechanical positive stop to protect against sudden pressure drops and overpressure situations. This model is versatile in its applications and can be mounted in various ways: subplate mounting, pipeline installation, flange connection in accordance with ISO standards, or as a vertical stacking element with sandwich plates. It offers different pressure ratings and adjustment types including spindle with or without protective cap, spindle with scale (with or without protective cap), rotary knob with scale, and lockable rotary knob with scale. The electrical connection options include valve plug-in connector design A and large cubic connectors with M x thread. For optimal performance and longevity of the HED 8 OP-2X/50K14KW SO16, it should be installed where there are low vibrations and safeguarded from hydraulic pressure surges. The micro switch within this unit can handle potential-free switching of currents ranging from mA to A and has UL approval for pressure ranges up to bar. This makes it an ideal component for various hydraulic systems requiring precise pressure monitoring and control.
