LFA32EWA-7X/CB40DQMG24A08P12T15

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LFA32EWA-7X/CB40DQMG24A08P12T15 (R901080950) is a sophisticated way cartridge valve designed for seamless integration into compact block systems. This valve is engineered to facilitate pressure, directional, and throttle functions, or a combination thereof, through the control of pilot valves. Its modularity allows it to be tailored for various flows corresponding to different actuator pathways, making it an exceptionally cost-effective solution for multifunctional applications. The model features a control cover that houses the control bores and may include additional functionalities such as stroke limitation, a hydraulically controlled directional seat valve, or a shuttle valve depending on the required function. It can also accommodate electrically operated directional spool or seat valves. The installation kit comprises essential components like a bushing, ring (up to NG), valve poppet (with or without damping nose), and closing spring. The functionality of this way cartridge valve is pressure-dependent with three critical pressurized areas A1, A2, A3 contributing to its operation. The areas A1 and A2 are active in the opening direction while area A3 along with the spring aids in closure. The force exerted by these areas determines the spool position within the valve. Designed for versatility, this model ensures unidirectional flow from A to B or vice versa with reliable blocking of channel A when area A3 is pressurized via pilot oil discharge from channel B or an external supply. Its power and flow-optimized design result in high flow rates with minimal pressure drops and leakage oil flows while maintaining high switching velocities. In addition to its functional capabilities, the LFA32EWA-7X/CB40DQMG24A08P12T15 boasts a robust build ensuring reliability and longevity. Its compact size and lightweight nature coupled with ease of serviceability make it an ideal choice for applications requiring precise hydraulic control within space-constrained environments.
