DBDS30G1X/160E

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBDS30G1X/160E (R901076141) is a direct operated seat valve designed for precise pressure relief in hydraulic systems. This model, part of the DBD series, serves as a safety device to limit system pressure and prevent potential damage due to overpressure conditions. The valve consists of a sleeve, spring, and a poppet with a damping piston for pressure ratings up to 315 bar or a ball for pressure ratings up to 630 bar. The pressure can be adjusted steplessly through various adjustment types provided. The DBDS30G1X/160E is engineered for versatility with multiple adjustment options, including a sleeve with hexagon and protective cap, rotary knob, hand wheel, or a lockable rotary knob. These features ensure user-friendly operation while maintaining the safety and integrity of the hydraulic system. The valve's design also includes an embossing that limits the stroke of the poppet to control flow from channel P into channel T when the set pressure is exceeded. In terms of mounting flexibility, this model can be installed as a screw-in cartridge valve or used in threaded connections and subplate mounting configurations. It offers reliable performance across its entire pressure range by utilizing different springs corresponding to specific maximum operating pressures. Notably, the adjustment mechanism is designed so it cannot be lost and remains movable even when completely unloaded due to its gimbal mounting. This ensures consistent performance even when adjustments are necessary due to changes in system conditions or requirements. Overall, the Bosch Rexroth DBDS30G1X/160E provides robust construction and precise control over hydraulic system pressures, making it an essential component for various applications requiring reliable pressure relief functionality.
