4WE6D46-6X/OFEW110RNXEZ2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6D46-6X/OFEW110RNXEZ2 (R901053749) is a high-performance directional spool valve designed to control the start, stop, and direction of fluid flow within a hydraulic system. This valve operates with two solenoid actuators and utilizes a wet-pin design for reliable actuation of the control spool. It is engineered with precision to maintain a central or initial position via return springs when de-energized, except for impulse spools. This model features an optional manual override that allows for manual operation in the absence of solenoid power, providing additional control flexibility. The 4WE6D46-6X/OFEW110RNXEZ2 valve is particularly suitable for applications requiring alternation between two spool positions without the need for continuous solenoid energization, thanks to its detent feature. Designed with safety and durability in mind, it includes measures to handle pressure peaks in the tank line and is equipped with an internal leakage feature that may increase throughout its lifecycle without compromising performance. It is also configured to incorporate a throttle insert if necessary due to operational conditions. The valve's suitability for use in potentially explosive atmospheres is certified under EU Explosion Protection Directive standards, with solenoids protected according to Ex eb mb IIC T Gb as per EN standards. It conforms to ISO porting patterns and offers flexible electrical connection options with individual connections and cable gland. Its robust construction and specialized features make it ideal for precise hydraulic flow management in various demanding applications while adhering to stringent safety regulations.
