R901019915

4WMM6E5X/FSO12

Manufacturer: Bosch Rexroth

Material #: R901019915

Model : 4WMM6E5X/FSO12


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WMM6E5X/FSO12 (R901019915) is a high-performance directional spool valve that is part of the WM.. series known for its mechanical, manually actuated design. This particular model is equipped with a hand lever for actuation, ensuring precise control over the start, stop, and direction of fluid flow within hydraulic systems. The valve features a robust housing that contains a control spool and one or two return springs. In its default state, these springs hold the control spool in a central or initial position. When the rotary knob with detent is engaged, it locks the spool into place in one of the selectable positions. This model also includes a throttle insert option to regulate flow during switching processes that might exceed the valve's performance limit; this insert can be placed in channel P. The 4WMM6E5X/FSO12 follows porting patterns according to DIN form A without locating holes and ISO with locating holes, providing versatility for various installation requirements. Additionally, it can accommodate inductive position switches and proximity sensors for contactless detection of spool position. The valve comes in 2-way or 3-way versions and boasts an impressive maximum operating pressure of up to 315 bar and can handle maximum flow rates up to 60 l/min. This combination of features makes the Bosch Rexroth 4WMM6E5X/FSO12 (R901019915) an essential component for precise hydraulic control in various applications where manual operation is preferred or required.

$1,007.00 USD

More are expected on May 22, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as May 22, 2025 when ordered in

This product is eligible for factory repair.
