INTERNAL GEAR PUMP PGF3-3X/020LJ07VU2

Manufacturer: Bosch Rexroth

Material #: R900948466

Model : PGF3-3X/020LJ07VU2

Destination

$2,369.00 USD

Availability: Backordered

Ships from US

Add to Cart

Qty:
Delivered as early as January 14, 2027

$2,487.45 USD

Availability: Backordered

Ships from CA

Add to Cart

Qty:
Delivered as early as January 14, 2027

INTERNAL GEAR PUMP PGF3-3X/020LJ07VU2

INTERNAL GEAR PUMP, size 20, pressure 250 bar for industrial and mobile applications, open circuit

Suitable for variable-speed drives, low noise and low pulsation, high efficiency thanks to gap compensation, suitable for two million load cycles at maximum pressure

Unpacked Weight: 5.5 kg

Aluminum housing
Internal gear pump with constant displacement
For industrial and mobile applications in the open circuit
With FKM seals
Maximum operating pressure 250 bar
Frame size 1, 2, 3
Size 1.7 … 40

Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Displacement type	constant
Size	20
Max. pressure	250
Max. flow	74.16
Shaft end	Geared 22-4, 13T 16/32 DP, ISO 3019-1
Through-drive	with
Direction of rotation	counterclockwise rotation
Shaft end	Geared 22-4, 13T 16/32 DP, ISO 3019-1
Mounting flange	2-hole mounting flange 101-2 according to ISO 3019-1
Hydraulic fluid	HL,HLP,HEES,HEPR
Seals	FKM
Fastening	2-hole mounting flange 101-2, ISO 3019-1
Speed min.	500
Productgroup ID	9,10,11,12,13,14
Speed max.	3600
Weight	5.5
