3DR16P5-5X/50Y/00V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR16P5-5X/50Y/00V (R900942090) is a sophisticated pressure reducing valve designed for maintaining and limiting system pressure within hydraulic circuits. This pilot-operated way pressure reducing valve is engineered to provide precise control over the secondary circuit's pressure levels. In its default state, the valve allows unrestricted flow from channel P to channel A, with the main valve featuring a control spool and a pilot control valve equipped with an adjustable pressure setting. The functionality of this Bosch Rexroth model ensures that when the pressure in channel A exceeds the set value on the compression spring, it triggers the ball to open, causing the control spool to shift to a closed position. This action balances out the pressures and achieves the desired reduced pressure level. If an external force causes further pressure increase in channel A, the control spool counteracts by connecting channel A to channel T, allowing excess hydraulic fluid to discharge into the tank and preventing further pressure rise. This model also features an external pilot oil return via port Y that requires a depressurized connection to ensure proper function. Additionally, it includes a pressure gauge connection for monitoring reduced pressure in channel A. The 3DR16P5-5X/50Y/00V is designed for subplate mounting with porting patterns that follow ISO standards. It offers various adjustment types such as rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, and rotary knob with scale. With its size component series X, this valve can withstand maximum operating pressures of up to bar and can handle maximum flow rates of l/min. The versatility and precision of this Bosch Rexroth valve make it an essential component for hydraulic systems requiring reliable pressure reduction and maintenance.
