LC50DR20E7X/

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LC50DR20E7X/ (R900938048) is a sophisticated hydraulic component designed to regulate pressure within a hydraulic system through its pressure reducing function. This cartridge valve is engineered for integration into standardized receiving holes according to DIN ISO specifications, and it is secured with a control cover that can accommodate either manual or electrically proportional pilot control valves for precise pressure adjustments. These pilot valves conform to mounting dimensions set by DIN standards, offering flexibility in system design. The LC50DR20E7X/ valve operates as a spool valve without an area difference at port B, meaning there are no effective areas at this port. This design ensures that in its rest position the valve remains open, allowing free flow from port B to port A. The pilot oil supply orifice channels the effective pressure at port A to the spring side of the spool. Under normal conditions and when the pressure set at the pilot control valve is not exceeded, the spool remains open due to spring force, allowing uninterrupted flow. When system pressure reaches the set limit, the spool moves to a closed position, triggering a reduction in pressure at port A as per the specific pressure-flow characteristics of this model. By combining different cartridge valves with appropriate control covers, users can achieve various pressure functions tailored to their hydraulic system's requirements. This particular model from Bosch Rexroth has been crafted with precision and reliability in mind, ensuring consistent performance in controlling hydraulic pressures and improving overall operational efficiency. Its robust design allows for maximum flow rates while maintaining stability and responsiveness within a broad range of hydraulic applications.
