LOGIC CARTRIDGE VALVE LC40DR40E7X/

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LC40DR40E7X/ (R900938018) is a high-performance, hydraulically actuated industrial hydraulic valve that offers reliable pressure reduction to a pre-set value. This model features a spool valve with a pilot-operated design and the spool symbol B A, ensuring precise control over hydraulic systems. The valve has a maximum pressure capacity suitable for demanding applications and is part of Productgroup ID. It boasts multiple ports of Size B A and can accommodate a max flow rate as specified by its design. The type of connection for this valve is a cartridge valve, which adheres to the ISO connection diagram standards. It has been designed for a number of switching positions and comes with an exact weight specification. The seals are made from NBR material, making them compatible with various types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. Bosch Rexroth's LC40DR40E7X/ valves are pilot-operated devices that come in either seat or spool configurations. The power section of this cartridge valve fits into a standardized receiving hole according to DIN ISO norms and is sealed with a control cover. Pilot control valves are either integrated into or mounted on this cover for manual or electrically proportional pressure adjustments following DIN standards. This particular model enables different pressure functions through combinations with control covers. Its pressure reducing function ensures that in the rest position the system remains open. The unique design of the spool valve without area difference at port B allows for free flow from port B to port A under certain conditions until the set pressure is reached, at which point the spool closes to reduce pressure at port A based on specific performance characteristics.
