DIRECTIONAL SPOOL VALVE 4WE6D6X/EG24N9DK25L/B10

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6D6X/EG24N9DK25L/B10 (R900917736) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction in accordance with the hydraulic symbol D. This direct-actuated spool valve features a spool symbol D and is capable of handling a maximum pressure with electrical actuation via solenoid. The valve is equipped with an electrical connection that includes a Brad Harrison MiniChange connector with LED, adhering to ANSI B.M standards. The 4WE6D6X/EG24N9DK25L/B10 valve offers various attributes such as a CETOP size D, NFPA T.3.5.1 R2 D05 size, and ISO 4401 porting pattern, providing versatility for different system requirements. The solenoid actuation ensures precise control, with the option of manual auxiliary actuation available for instances where magnet supply is not present. Designed for durability and efficiency, the valve supports multiple types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. It comes with NBR seals to ensure compatibility and longevity within diverse operational environments. The unit has a supply voltage requirement of 24 VDC and includes two switching positions to facilitate the control of flow direction. Additional features include optional spool position monitoring for enhanced operational awareness and high-power solenoids that can be rotated by 90 degrees for flexible installation orientations. It also complies with CE conformity standards under the Low-Voltage Directive EU for electrical voltages greater than 50 VAC or 75 VDC. The Bosch Rexroth directional valve model accommodates both single and central electrical connections and offers optional auxiliary operating devices for increased control versatility. Its solenoid coil holds UR marking approval according to UL standard edition 7, with additional CSA C22.2 No. 139 approval available as an option. This robust directional control valve is suitable for various applications requiring precise fluid management in complex hydraulic systems while ensuring energy-efficient operation through its advanced design features such as soft switching behavior to minimize wear during switching events.
